57/900 High Rib Trapeze

57/900 High Rib Trapeze
57/900 High Rib Trapeze

57/900 High Rib Trapeze

Features:

  • Corrosion Resistance
  • Long Lasting

Technical Drawing:

Maximum Load Capacity of 57/900 Trapezoidal Form

  Galvanized Sheet Thickness (mm)
Openness (m) 0,50 0,60 0,70 0,80 0,90 1,00 1,20
1,00 1.464 1.753 2.040 2.327 2.613 2.897 3.462
1,50 651 779 907 1.034 1.161 1.288 1.539
2,00 366 438 510 582 653 724 865
2,50 145 173 202 230 258 286 342
3,00 163 195 227 259 290 322 385
  • The tables are designed according to the method of safety stresses and EN 1993-1-3 (2006): Eurocode 3 Design of steel structures Part-1-3 Cold-formed steel.
  • Steel yield strength was used as 330 N/mm² in the calculations.
  • The loads in the tables are given as kg/m² and the values are given according to the multi-span continuous beam calculation.
  • The tolerance values used in the calculations are given in accordance with TS EN 10143 Continuous Hot Dip Metal Coated Steel Strips and Plates-Size and Shape Tolerances Standard.
  • The maximum deflection limit was loaded with L/200.

Coating Types

It offers high resistance to external environmental conditions, high level of flexibility and temperature balance. This type of paint has a wide range of uses and is among the most widely preferred. Ideal for a variety of purposes indoors and outdoors, it offers a versatile solution.

It provides superior durability and high corrosion resistance against the harsh effects of the external environment. It is also resistant to chemicals. This type of coating also offers strong protection against chemicals and UV rays. The permanence and brightness of its colors are at the highest level, distinguishing it from other coating types. For this reason, it is a preferred coating option on the roofs and facades of prestigious buildings.

It has a wonderfully malleable and flexible structure. It is resistant to moisture and abrasion and is preferred in applications that comply with food regulations. Additionally, it exhibits superior performance in cold and humid climate conditions.

Its application is carried out by the lamination method. It is an ideal choice in areas that require intense shaping and flexibility. Its hygienic and easy-to-clean features provide a significant advantage for applications that comply with food regulations.
